Name: Banner Engineering XS26-2
SKU: 275668

Product Details ＋

Product Attribute	Attribute Value
Dimensions	110 x 45 x 129
Display	No
Expandable	Yes
IP Rating	IP20
Maximum Operating Temperature	55 °C
Minimum Operating Temperature	0 °C
Module Type	Base
Number of I/O Ports	26
Operating Temperature	0 to 55
Series
Terminal Type	Screw
Termination	Screw
Voltage, Operating	24 V dc /- 20% VDC

Overview

Control System monitors a variety of input devices such as e-stop buttons, rope pulls, enabling devices, protective safety stops, interlocked guards or gates, optical sensors, two-hand controls, and safety mats

Pre-configured safety function blocks including Two-Hand Control, Muting, and Enabling Device to simplify application programming

Boolean logic functions for programming flexibility

Intuitive programming environment for easy implementation

Expandable models for adding up to 8 additional I/O modules for larger scale applications

Base Controller allows 8 of the 26 inputs to be configured as outputs for efficient terminal utilization

Ethernet models available providing up to 64 virtual status outputs

Optional onboard LCD display for system status and diagnostic information
